In bottled water and PET beverage production, every minute of line downtime translates into thousands of unfinished bottles — and every wrinkled sleeve translates into shelf rejections at retail. The YCT-300 high-speed shrink sleeve labeling machine is engineered specifically for mineral water, purified water, and PET beverage bottlers who run continuous high-volume lines and cannot tolerate label drift, skew, or missed sleeves at 250+ BPM.
Manufactured by Dongguan Yucheng Machinery Technology Co., Ltd. (YCT Machinery) — a CE-certified packaging equipment maker with 15+ years of export experience to 50+ countries — the YCT-300 is the production-grade choice for bottlers serving supermarket chains, food-service distributors, and export brands who need consistent shelf presentation at industrial speed.
The YCT-300 is not a "general purpose" sleever scaled up. It's optimized for the specific demands of PET water and beverage bottling:
High-speed PET handling — Designed around the lightweight, slightly flexible nature of PET water bottles, with brush-down and bottle-carrying groups tuned to avoid bottle deformation at 300 BPM.
Steam shrink compatibility — The standard shrink method for water bottles, delivering the glossy, ripple-free finish required by mainstream water brands.
Continuous-shift duty — Built for 16-hour and 24-hour operation with MTBF above 4,000 hours reported by long-term EU and US customers.
PET sleeve film optimization — Compatible with the thin (0.03–0.13 mm) PVC, PET, OPS, and PETG sleeve films most commonly used in the water/beverage segment.
Line integration — Designed to drop into existing water bottling lines downstream of blow molders and fillers, or as part of a YCT turnkey line.
Parameter | YCT-300 Specification |
Model | YCT-300 |
Industry Focus | Mineral water, purified water, PET beverage |
Labeling Speed | 150 – 300 bottles/min (adjustable) |
Applicable Bottle Diameter | Φ38 mm – Φ120 mm |
Sleeve Label Length | 30 mm – 220 mm |
Sleeve Label Thickness | 0.03 mm – 0.13 mm (PVC / PET / OPS / PETG) |
Inner Paper Tube Diameter | 5" – 10" (freely adjustable) |
Power Supply | 220V, 3.0 kW (110V / 380V / 415V on request) |
Machine Dimensions | 2,600 mm (L) × 900 mm (W) × 2,000 mm (H) |
Net Weight | 400 kg |
Frame Material | 304 stainless steel (food-grade, corrosion-resistant) |
Control System | Mitsubishi PLC + Kunlun Tongtai touchscreen HMI (bilingual EN/CN) |
Servo System | Schneider (France) servo motor + servo driver |
Photoelectric Sensors | Panasonic (Japan) |
Bearings & Belts | NSK bearings (Japan), GATES drive belts (USA) |
Heat Shrink Option | Steam tunnel (recommended for water/PET) or electric heating tunnel |
Certification | CE Certified, ISO 9001:2015 |
If you're producing bottled water for a supermarket chain or export market, sleever throughput directly drives your daily output ceiling. Here's the math:
Speed | Per Shift (8h) | Per Day (16h, 2 shifts) | Per Day (24h, 3 shifts) |
100 BPM (YCT-100) | ~48,000 bottles | ~96,000 bottles | ~144,000 bottles |
200 BPM (YCT-200) | ~96,000 bottles | ~192,000 bottles | ~288,000 bottles |
300 BPM (YCT-300) | ~144,000 bottles | ~288,000 bottles | ~432,000 bottles |
For a mid-sized water bottler producing 500 ml SKUs, 300 BPM is the threshold where the sleeve applicator stops being the line bottleneck and matches the throughput of high-speed PET fillers and cappers downstream.
All three single-head models share the same trusted engineering platform — the right model depends on your target throughput and product mix:
Comparison | YCT-100 | YCT-200 | YCT-300 |
Industry Focus | General bottling | General bottling | Mineral water / PET beverage |
Top Speed | 100 BPM | 200 BPM | 300 BPM |
Power | 2.0 kW | 2.0 kW | 3.0 kW |
Machine Length | 2,100 mm | 2,100 mm | 2,600 mm |
Weight | 280 kg | 280 kg | 400 kg |
Best For | Pilot lines, SMEs | Mid-large bottlers | Large water/beverage bottlers, export brands |
Recommended Shrink | Steam or electric | Steam or electric | Steam (standard for water) |
Rule of thumb: if your line is primarily bottling water or PET beverages, and your daily target is above ~140,000 bottles per shift, the YCT-300 is the right choice.
The YCT-300 handles the full range of mainstream PET water and beverage bottle sizes through interchangeable center guide pillars:
Bottle Size | Typical Diameter | YCT-300 Compatibility |
250 ml mini water bottle | Ø ~52 mm | ✅ Yes |
330 ml beverage bottle | Ø ~55 mm | ✅ Yes |
500 ml standard water bottle | Ø ~60–65 mm | ✅ Yes (most common) |
600 ml sports water | Ø ~63 mm | ✅ Yes |
1 L beverage bottle | Ø ~85 mm | ✅ Yes |
1.5 L family water bottle | Ø ~90–100 mm | ✅ Yes |
2 L family bottle | Ø ~110–120 mm | ✅ Yes |
For non-standard or custom-shaped bottles within Ø38–Ø120 mm, we provide custom guide pillars and cutter heads at no extra design fee.
For mineral water and PET beverage applications, steam shrink is the industry standard — and the YCT-300 is engineered to feed bottles into a steam tunnel at sustained 300 BPM without spacing errors. Steam shrink delivers:
Glossier, smoother sleeve appearance — critical for premium water brands on supermarket shelves
Tolerance to label material and color variations — lower QA rejects
Lower-grade sleeve film acceptable — reduces your per-bottle label cost at high volumes
Even heat distribution — eliminates the wrinkles that electric tunnels can produce at 250+ BPM
We supply matched steam shrink tunnels with the YCT-300 — sized to your throughput, with the right number of heating zones for your specific bottle and sleeve material. Tell us your bottle and label specs and we'll engineer the full sleeving line for you.
Note: electric shrink tunnels remain available if your product or factory environment requires it — typical for glass-bottle premium water lines.
Pushing a single-head sleever to 300 BPM is engineering, not luck. The YCT-300 achieves it through:
Heavier-gauge 304 stainless steel frame (400 kg vs 280 kg on YCT-100/200) that absorbs vibration from sustained high-speed servo cycles.
3.0 kW power supply with margin headroom — components never operate at peak rating, extending service life.
Mitsubishi PLC + Schneider servo — accurate signal processing and low-backlash servo control even at maximum speed.
Panasonic photoelectric sensors — millisecond bottle detection that keeps spacing stable at 300 BPM.
NSK bearings + GATES drive belts — globally available spares, dimensioned for high-cyclic load.
Kunlun Tongtai bilingual HMI — single-screen control with diagnostics; Russian, Spanish, Arabic, Vietnamese, and Thai available on request.
Long-term water bottling customers in the EU and US markets report average MTBF above 4,000 hours on the YCT-300 in continuous-shift operation.
One YCT-300 base machine can be configured for:
Different bottle diameters (Ø38–Ø120 mm) via interchangeable center guide pillars
Different sleeve materials — PVC, PET, OPS, PETG
Sleeve cutting modes — transparent-gap photoelectric, color-mark registration, or fixed-length cutting
Voltage adaptation — 110V / 220V / 380V / 415V
HMI language — English, Chinese, Russian, Spanish, Arabic, Vietnamese, Thai, and more
OEM branding — machine color and logo customizable
Line integration — downstream of blow molder/filler/capper, upstream of conveyor/case packer
15+ years of manufacturing experience — R&D, production, sales, and after-sales under one roof in Dongguan, China.
Exported to Southeast Asia, Russia, Japan, South Korea, Vietnam, Cambodia, Thailand, Myanmar, Nepal, Ethiopia, and EU/US markets.
CE Certified · ISO 9001:2015 — SGS / TÜV third-party inspection reports available on request.
Free water-line sample test — send us your PET bottles and sleeves; we'll record a 300 BPM test video before shipment.
Same-day technical response — WhatsApp and video-call support from our engineering team.
Spare parts shipped within 48 hours — and on-site commissioning available in 30+ countries through partner integrators.
NDA available on request — for confidential product launches and OEM water brands.
The YCT-300 is delivered pre-assembled, factory-tested at full 300 BPM with your sample bottles, and packaged in fumigation-treated wooden crates. Upon arrival, our team supports:
Step-by-step video commissioning (English / Chinese / customer language on request)
Remote video-call setup with our engineers
On-site commissioning in 30+ countries via local partner integrators
Operator training focused on high-speed PET handling, steam tunnel coordination, label film loading, photoelectric calibration, and routine maintenance
Voltage stabilizer recommendation for regions with unstable power supply (protects PLC and servo electronics)
The YCT-300 is optimized for mineral water and PET beverage bottles, but it handles any PET, HDPE, glass, or aluminum bottle within Ø38–Ø120 mm — including juice, tea, sports drinks, dairy, condiments, and cosmetic containers. The name reflects its most common use case, not a hardware limitation.
Yes — when paired with a correctly sized steam shrink tunnel, upstream filler/capper synchronized to 300 BPM, and quality PVC/PET sleeve film. Long-term water bottling customers in the EU and US report average MTBF above 4,000 hours at sustained 250–300 BPM. We factory-test every YCT-300 at full speed with your sample bottles before shipment, and send you the test video for confirmation.
Pricing depends on configuration — base sleever, steam vs electric shrink tunnel, voltage, HMI language, custom guide pillars, and whether you need a complete water sleeving line quote. Send us your bottle samples and target speed for a full quote within 24 hours.
Standard lead time is 30–40 working days after deposit, depending on customization. We ship FOB Shenzhen / Guangzhou by default, with CIF, DDP, and air freight options available. Export packaging is fumigation-treated wooden crate, suitable for sea freight to any port worldwide.
Yes — by swapping the center guide pillar and adjusting machine height and photoelectric positions. The machine accepts bottles from Ø38 mm (typical small bottle) to Ø120 mm (2 L family bottle). For large diameter changes you may also need to swap the cutter head. We pre-build all required guide pillars and cutters for your SKU range and include them in the delivery.
Steam tunnels deliver more even heat distribution at high speed, producing the smooth, glossy sleeve finish that mainstream water brands need for shelf presentation. Steam shrink also accepts lower-grade sleeve film without quality compromise, reducing label cost at high volumes. Electric shrink is technically possible but rarely chosen for PET water lines.
Yes — the YCT-300 is modular by design with standard conveyor sections that connect to upstream blow molders, fillers, and cappers, and downstream case packers. If you'd like a complete turnkey water line (blow molder → filler → capper → sleever → shrink tunnel → packer), we can quote and engineer the entire system as one project.
Yes. The YCT-300 handles sleeve film thicknesses from 0.03 mm to 0.13 mm, covering PVC, PET, OPS, and PETG. Our engineering team will recommend the right shrink rate, color, and material based on your bottle, target shelf appearance, and shrink tunnel type.
The YCT-300 is CE certified and manufactured under ISO 9001:2015. SGS and TÜV third-party inspection reports are available on request. Food-contact components use 304 stainless steel (316 available on request) and comply with FDA contact-surface standards — important for bottled water producers.
Yes. We provide:
Free remote commissioning via video call (same-day response on WhatsApp)
On-site commissioning through partner integrators in 30+ countries
24-month warranty on the main machine (excluding wear parts)
Spare parts shipped within 48 hours from our Dongguan warehouse
Lifetime technical support from our engineering team
The YCT-300 runs 150–300 BPM (vs 100–200 BPM for the YCT-200), uses a heavier frame (400 kg vs 280 kg) and higher power (3.0 kW vs 2.0 kW) to sustain higher speeds, and is specifically tuned for PET water and beverage bottles. The YCT-200 is the right choice for mid-range mixed-SKU bottling; the YCT-300 is the right choice when water/beverage throughput is your primary KPI.
Absolutely. We routinely customize:
Machine color and logo (OEM branding available)
HMI language — English, Chinese, Russian, Spanish, Arabic, Vietnamese, Thai, and more
Voltage — 110V / 220V / 380V / 415V
Sleeve cutting mode — gap mark, color mark, or fixed-length
Tell us your bottle size, daily target, and shrink tunnel preference — we'll send you a tailored YCT-300 quote, a free 300 BPM sample-test video on your bottles, and a recommended water-line configuration within 24 hours.
